Pneumatic Grippers - QPG-tech
Three-finger centric gripper suitable for a wide range of industrial applications.
- -Robust and lightweight housing made of hard-coated aluminum alloy.
- -Sturdy T-slot with hardened steel gibs for effective jaw guidance, precise handling, and easy maintenance.
- -Compact dimensions for minimal impact in space sensitive applications.
- -Mounting from one side in two screw directions for versatile and flexible integration.
- -Integrated permanent magnets for direct monitoring of piston movement.
- -Slots for mounting and positioning of magnetic-field sensors
- -Air supply via hose-free direct connections or fitting screw connections.
- -Available in 6 sizes (QPG-Tech 208, 210, 212, 216, 220, 230)
- -Maximum stroke per jaw of 30 mm
- -Maximum total closing force @ 6 bar: 8100N (1820.9 lbf)
-
